AEROFLEX-IFR 2040 CALIBRATION and AEROFLEX-IFR 2040 REPAIR


A calibration by Custom-Cal is performed by engineers with extensive OEM experience. We have the expertise and the necessary standards to perform the AEROFLEX-IFR 2040 Calibration, onsite calibration may be available. We specialize in quick turnaround times and we can handle expedited deliveries upon request.

Need another Signal Generator?
Shop for Comparable Products on our
 used Signal Generator page


   AEROFLEX-IFR 2040   Description / Specification:
AEROFLEX-IFR 2040 1.35 GHz Low Noise Signal Generator

The IFR-Aeroflex 2040 1.35 GHz Low Noise Signal Generator has a choice of operating modes, two low noise modes for improved SSB phase noise and normal mode for increased flexibility, the 2040 can be used in a wide variety of applications. Microprocessor control coupled with a large screen dot matrix display provides ease of use via menu driven displays. Set up time is further reduced by recalling previously stored instrument settings from the non-volatile memory. Remote programming via the GPIB is provided as a standard feature, allowing the instruments to be incorporated in automatic test systems. With a specified SSB phase noise performance of better than - 140 dBc/Hz at 20 kHz offset from a carrier of 1 GHz, the 2040 of signal generator is easily able to measure UHF receiver selectivities beyond 90 dB. The low residual FM noise figure (less than 0.3 Hz RMS at 1 GHz) gives the 2040 the capability of measuring UHF receiver signal to noise ratios as high as 80 dB. Carrier frequency entry is selected via a soft key option on the signal generator screen and data is then entered directly via the keyboard. Frequency is resolved to within 0.1 Hz across the complete range of the instrument. Carrier frequencies can be stored in the non-volatile memory for recall at any time. RF output up to +13 dBm can be set by direct keyboard entry with a resolution of 0.1 dB or better over the entire range. An electronic trip protects the generator output against reverse power of up to 50 W, preventing damage to output circuits when RF or DC power is accidentally applied. An internal modulation oscillator is provided with a frequency range of 0.1 Hz to 500 kHz, resolved to 0.1 Hz. Four modulation modes are provided - single, dual, composite and dual composite. Specifications. Carrier Frequency Range: 10 kHz to 1.35 GHz. Resolution: 0.1 Hz. RF Output Range: - 144 dBm to +13 dBm, When AM is selected the maximum output level reduces linearly with AM depth to + 7 dBm at maximum AM depth. Resolution: 0.1 dB. Modulation Oscillator Frequency Range: 0.1 Hz to 500 kHz. Option 001, Second internal modulation oscillator. Option 002, Pulse Modulation. Option 003, + 19 dBm Output Level. Option 006, Avionics (requires Option 001, not with Option 003). Option 008, RF Profile and Complex Sweep. Option 012, Electronic attenuator (not available with option 003). Option 105, Modifies the pulse modulation option for slower rise and fall time (order with Option 002). Option 112, Ext. mod 2 Input 600 ohm.





Standard Calibration $565.00 *
Click on Logo for More Prices
*This is a Web introductory price for one calibration of the AEROFLEX-IFR 2040. Price does not in most cases include measurement performance data. Pricing does include NIST traceable calibration and issue of a calibration certificate and calibration label. Pricing may vary slightly due to volume and location of laboratory supporting calibration. Volume pricing may apply. On-site fees may apply depending on logistics, location and volume of work to be completed during the visit.


Related Bench Equipment Terms and Definitions. For a complete list go to our  Terms and Definitions Page.

dBc
dBc (decibels relative to the carrier) is the power ratio of a signal to a carrier signal, expressed in decibels. If the dBc figure is positive, then the relative signal strength is greater than the carrier signal strength. If the dBc figure is negative, then the relative signal strength is less than carrier signal strength.

Load Regulation
Load regulation is the capability to maintain a constant voltage (or current) level on the output channel of a power supply despite changes in the supply's load (such as a change in resistance value connected across the supply output).

Power Linearity
When changing the power level and measuring the differences (in dB) between actual and displayed power levels, the power linearity is ± half the span (in dB) between the maximum and the minimum value of all differences.

Settling Time
Settling time of an output device is the time elapsed from the application of an ideal instantaneous step input to the time at which the amplifier output has entered and remained within a specified error band, usually symmetrical about the final value.


Please contact us for your AEROFLEX-IFR 2040 CALIBRATION and/or AEROFLEX-IFR 2040 1.35 GHz Low Noise Signal Generator REPAIR
