KEITHLEY 2400-LV REPAIR and KEITHLEY 2400-LV CALIBRATION


Custom-Cal has a high success rate in the repair of the KEITHLEY 2400-LV. A calibration by Custom-Cal is performed by engineers with extensive OEM experience. We have the expertise and the necessary standards to perform the KEITHLEY 2400-LV Calibration, onsite calibration may be available. We specialize in quick turnaround times and we can handle expedited deliveries upon request.

Need another General Meter?
Shop for Comparable Products on our
 used General Meter page


   KEITHLEY 2400-LV   Description / Specification:
KEITHLEY 2400-LV

SourceMeter w/ Measurements up to 20V and 1A, 20W Power Output: Five instruments in one (IV Source, IVR Measure). Six models: 20 - 100W DC, 1000W pulsed, 1100V to 1«V, 10A to 10pA. Source and sink (4-quadrant) operation. 0.012% basic measure accuracy with 5½-digit resolution. 2-, 4-, and 6-wire remote V-source and measure sensing. 1700 readings/second at 4½ digits via GPIB. Pass/Fail comparator for fast sorting/binning. Available high speed sense lead contact check function. Programmable DIO port for automation/handler/prober control. Standard SCPI GPIB, RS-232, and Keithley Trigger Link interfaces. Keithley LabTracer 2.0 I-V curve tracing application software (download). Each SourceMeter instrument is both a highly stable DC power source and a true instrument-grade 5-1/2 digit multimeter.





Standard Calibration $285.00 *
Click on Logo for More Prices
*This is a Web introductory price for one calibration of the KEITHLEY 2400-LV. Price does not in most cases include measurement performance data. Pricing does include NIST traceable calibration and issue of a calibration certificate and calibration label. Pricing may vary slightly due to volume and location of laboratory supporting calibration. Volume pricing may apply. On-site fees may apply depending on logistics, location and volume of work to be completed during the visit.


Related Bench Equipment Terms and Definitions. For a complete list go to our  Terms and Definitions Page.

Crest Factor
Crest factor or peak-to-average ratio (PAR) is a measurement of a waveform, calculated from the peak amplitude of the waveform divided by the RMS value of the waveform

Linearity
Linearity is the relative difference between the displayed power ratio, Dx/D0, and the actual (true) power ratio Px/P0 caused by changing the displayed power level from the reference level, D0, to an arbitrary displayed level, Dx.

Phase Noise
Phase noise is the frequency domain representation of rapid, short-term, random fluctuations in the phase of a waveform, caused by time domain instabilities. Phase noise (L(f)) is typically expressed in units of dBc/Hz, representing the noise power relative to the carrier contained in a 1 Hz bandwidth centered at a certain offsets from the carrier.

Sensitivity
Sensitivity is the minimum magnitude of input signal required to produce a specified output signal having a specified signal-to-noise ratio, or other specified criteria.


Please contact us for your KEITHLEY 2400-LV REPAIR and/or KEITHLEY 2400-LV CALIBRATION
