The Tektronix 466 100 MHz Dual-Trace Oscilloscope specifications. Bandwidth: Dc to 100 MHz, <=3.5 ns. Deflection Factor: 5mV/div to 5V/div in 10 calibrated steps, (1-2-5 sequence); accurate within 3%; continuously variable between steps and to approximately 12.5 volts/div. Maximum Input Voltage: Dc Coupled; 250 V (dc + peak ac), 500 V (p-p ac at 1 kHz or less), Ac Coupled; 500 V (dc + peak ac), 500 V p-p (ac at 1 kHz or less). Time Base A: 0.05, us/div to 0.5 s/div in 22 calibrated steps (1-2-5 sequence). X10 MAG extends maximum sweep rate to 5 ns/div. Time Base B: 0.05, us/div to 50 ms/div in 19 calibrated steps (1-2-5 sequence). X10 MAG extends maximum sweep rate to 5 ns/div. Calibrated Sweep Delay: Continuously variable from 0.2 us to at least 5 seconds. Triggering: A Trigger Modes; Normal (sweep runs when triggered), Automatic (sweep free-runs in the absence of a triggering signal), Single Sweep (sweep runs one time on the first triggering event after the reset selector is pressed). B Trigger Modes; B Runs After Delay Time (starts automatically at the end of the delay time), B Triggerable After Delay Time (runs when triggered), the B (delayed) sweep runs once, in each of these modes, following the A sweep delay time. X-Y Operation: Full-sensitivity X-Y (CH 1 Horiz, CH 2 Vert)- 5 mV/div to 5 V/div in 10 calibrated steps, accurate within 4%. Bandwidth is dc to at least 4 MHz. CRT: Internal graticule with variable illumination; 8 x 10 div, 0.9 cm/div (normal) ; 8 x 10 div, 0.45 cm/div (reduced scan).
|
